WAVERIDER 470
The GEMINI Waverider 470 with its deep vee hull sizes up convenience and launches a new era in versatility.
Today the Waverider Series is in use with commercial, military and rescue operations worldwide.
STANDARD FEATURES
Hypalon tubes (1100Dtex)
Heavy duty shark fin rubbing strake
Full length grab line
3 x Inflation Valves
3 x Over pressure release valves
Internally taped seams
2 x Paddles
Stainless steel bow eye
Anchor rope bow protection
Anchor locker
Transom knee
2 x Towing points
Self-draining deck
Non-slip deck
1 x Double action pump
1 x Repair kit
SPECIFICATIONS
| Model | 470 |
| LENGTH OVERALL (LOA) | 4.7M |
| INTERNAL LENGTH (MOTOR WELL TO ANCHOR LOCKER) | 2.58 |
| BEAM OVERALL | 2M |
| BEAM INTERNAL | 1.08 |
| TUBE DIAMETER | 460 |
| TUBE VOLUME | 1.514 |
| NO. OF TUBE COMPARTMENTS | 5 |
| INFLATION PRESSURE | 0.25BAR |
| WEIGHT EMPTY | 160 |
| MAX WEIGHT | 1135 |
| MAX PERSONS | 10 |
| MAX LOAD | 975 |
| REC HP/ (KW) | 60 |
| MAX HP/ (KW) ISO 6185-3 | 70 |
| MAX ENGINE WEIGHT AS PER SAMSA BOUYANCY CERTIFICATE (KILOGRAMS) | 120 |
| TRANSOM HEIGHT - SINGLE ENGINE INSTALLATION | L:20"(508) |
| TWIN ENGINE INSTALLATION | L:20"(508) |
| HULL DEADRISE (DEGREES) | 15 |
Please note photos are indicative only and may show additions not included in standard features. Errors and omissions excepted.
